SECTION 6: ELECTRICAL PARTS LIST
*
Items marked with an asterisk are not stocked since they
are seldom required for routine service. Expect some delay
when ordering these components.
RESISTORS
• All resistors are in ohms
• F : nonfl ammable
• All variable and adjustable resistors
have characteristic curve B, unless
otherwise noted.
REF. NO. PART NO. DESCRIPTION VALUES
The components in this manual identifi ed by the following
symbol:
X
indicate parts that have been carefully factory-
selected to satisfy regulations regarding X-ray radiation for
each set.
Should replacement be required for one of these
components, replace only with the value originally used.
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es par un trame et
une marque
!
sont critiques pour la securite. Ne
les remplacer que par une piece portant le numero
specifi e.
When ordering parts by reference
number, please include the board name.
REF. NO. PART NO. DESCRIPTION VALUES
A
A
* A-1299-514-A A COMPLETE PC BOARD
4-382-854-01 SCREW (M3X8), P, SW (+)
CAPACITOR
C001 1-162-318-11 CERAMIC 0.001µF 10% 500V
C002 1-162-318-11 CERAMIC 0.001µF 10% 500V
C003 1-102-050-00 CERAMIC 0.01µF 20% 500V
C004 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C007 1-126-935-11 ELECT 470µF 20% 16V
C009 1-126-926-11 ELECT 1000µF 20% 10V
C010 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C011 1-130-777-00 MYLAR 0.1µF 10% 100V
C012 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C013 1-162-318-11 CERAMIC 0.001µF 10% 500V
C014 1-128-562-11 ELECT 47µF 20% 100V
C015 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C016 1-126-947-11 ELECT 47µF 20% 25V
C018 1-107-649-11 ELECT 2.2µF 20% 250V
C022 1-126-947-11 ELECT 47µF 20% 25V
C035 1-162-114-00 CERAMIC 0.0047µF 2KV
C036 1-162-318-11 CERAMIC 0.001µF 10% 500V
C042 1-163-009-91 CERAMIC CHIP 0.001µF 10% 50V
C044 1-163-251-11 CERAMIC CHIP 100pF 5% 50V
C046 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C047 1-126-947-11 ELECT 47µF 20% 25V
C049 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C050 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C053 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C054 1-137-528-11 MYLAR 0.1µF 10% 250V
C092 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C102 1-137-528-11 MYLAR 0.1µF 10% 250V
C104 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C105 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C106 1-137-528-11 MYLAR 0.1µF 10% 250V
C112 1-163-231-11 CERAMIC CHIP 15pF 5% 50V
C151 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C202 1-137-528-11 MYLAR 0.1µF 10% 250V
C204 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C205 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C206 1-137-528-11 MYLAR 0.1µF 10% 250V
C212 1-163-231-11 CERAMIC CHIP 15pF 5% 50V
C251 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C302 1-137-528-11 MYLAR 0.1µF 10% 250V
C304 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C305 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C306 1-137-528-11 MYLAR 0.1µF 10% 250V
C312 1-163-229-11 CERAMIC CHIP 12pF 5% 50V
C351 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
CONNECTOR
CN301 1-785-879-11 CONNECTOR, ONE TOUCH
* CN302 1-815-022-11 PIN,CONNECTOR (WITH PWB) 6P
* CN304 1-564-524-11 PLUG,CONNECTOR 9P
CN306 1-506-108-41 PIN,CONNECTOR (TERMINAL PIN)
CN307 1-695-915-11 TAB (CONTACT)
* CN309 1-564-523-11 PLUG,CONNECTOR 8P
DIODE
D001 8-719-970-02 DIODE 1SR139-400T31
D104 8-719-970-83 DIODE HSS82-TJ
D105 8-719-970-83 DIODE HSS82-TJ
D106 8-719-970-83 DIODE HSS82-TJ
D111 8-719-062-51 DIODE 1PS226-115
D204 8-719-970-83 DIODE HSS82-TJ
D205 8-719-970-83 DIODE HSS82-TJ
D206 8-719-970-83 DIODE HSS82-TJ
D211 8-719-062-51 DIODE 1PS226-115
D304 8-719-970-83 DIODE HSS82-TJ
D305 8-719-970-83 DIODE HSS82-TJ
D306 8-719-970-83 DIODE HSS82-TJ
D311 8-719-062-51 DIODE 1PS226-115
FERRITE BEAD
FB001 1-412-911-11 FERRITE 0µH
FB003 1-412-911-11 FERRITE 0µH
FB004 1-412-911-11 FERRITE 0µH
FB005 1-412-911-11 FERRITE 0µH
