— 30 —
P792
NOTE: The components identifi ed by shading
and ! mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es par un trame et une
marque ! sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES
FB006 1-412-911-11 FERRITE 0µH
FB009 1-412-911-11 FERRITE 0µH
FB010 1-412-911-11 FERRITE 0µH
FB101 1-412-911-11 FERRITE 0µH
FB102 1-216-295-91 SHORT
FB201 1-412-911-11 FERRITE 0µH
FB202 1-216-295-91 SHORT
FB301 1-412-911-11 FERRITE 0µH
FB302 1-216-295-91 SHORT
IC
IC001 8-752-094-09 IC CXA2067AS
IC002 8-759-596-65 IC LM2415T
IC003 8-759-698-56 IC CXD9620P
IC004 8-749-016-27 IC H8D2957
JACK
! J001 1-451-524-11 SOCKET, CRT
CHIP CONDUCTOR
JR002 1-216-296-11 SHORT
JR003 1-216-296-11 SHORT
JR004 1-216-296-11 SHORT
JR005 1-216-296-11 SHORT
JR007 1-216-296-11 SHORT
JR008 1-216-296-11 SHORT
COIL
L002 1-412-911-11 FERRITE 0µH
L005 1-400-054-21 INDUCTOR 22µH
L007 1-408-617-31 INDUCTOR 180µH
L105 1-410-750-41 INDUCTOR 0.47µH
L205 1-410-750-41 INDUCTOR 0.47µH
L305 1-410-750-41 INDUCTOR 0.47µH
TRANSISTOR
Q006 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
RESISTOR
R001 1-216-295-91 SHORT
R002 1-216-043-91 RES-CHIP 560 5% 1/10W
R003 1-216-071-00 RES-CHIP 8.2K 5% 1/10W
R004 1-216-055-00 RES-CHIP 1.8K 5% 1/10W
R005 1-216-109-00 RES-CHIP 330K 5% 1/10W
R006 1-216-025-11 RES-CHIP 100 5% 1/10W
R009 1-216-073-91 RES-CHIP 10K 5% 1/10W
R014 1-216-025-11 RES-CHIP 100 5% 1/10W
R017 1-216-025-11 RES-CHIP 100 5% 1/10W
R018 1-216-025-11 RES-CHIP 100 5% 1/10W
R020 1-216-017-91 RES-CHIP 47 5% 1/10W
R021 1-216-017-91 RES-CHIP 47 5% 1/10W
R024 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R028 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R030 1-216-049-11 RES-CHIP 1K 5% 1/10W
R032 1-216-097-11 RES-CHIP 100K 5% 1/10W
R033 1-247-891-00 CARBON 330K 5% 1/4W
R048 1-219-398-51 METAL 2.2M 5% 1W
R051 1-216-049-11 RES-CHIP 1K 5% 1/10W
R052 1-216-073-91 RES-CHIP 10K 5% 1/10W
R102 1-216-113-00 RES-CHIP 470K 5% 1/10W
R104 1-216-009-91 RES-CHIP 22 5% 1/10W
R106 1-216-673-11 METAL CHIP 8.2K 0.50% 1/10W
R107 1-216-651-11 METAL CHIP 1K 0.50% 1/10W
R108 1-216-674-11 METAL CHIP 9.1K 0.50% 1/10W
R109 1-216-113-00 RES-CHIP 470K 5% 1/10W
R111 1-249-405-11 CARBON 100 5% 1/4W
R117 1-249-402-11 CARBON 56 5% 1/4W
R119 1-216-121-11 RES-CHIP 1M 5% 1/10W
R130 1-216-022-00 RES-CHIP 75 5% 1/10W
R151 1-219-742-11 CARBON 47 5% 1/2W
R161 1-215-394-00 METAL 75 1% 1/4W
R202 1-216-113-00 RES-CHIP 470K 5% 1/10W
R204 1-216-009-91 RES-CHIP 22 5% 1/10W
R206 1-216-673-11 METAL CHIP 8.2K 0.50% 1/10W
R207 1-216-651-11 METAL CHIP 1K 0.50% 1/10W
R208 1-216-674-11 METAL CHIP 9.1K 0.50% 1/10W
R209 1-216-113-00 RES-CHIP 470K 5% 1/10W
R211 1-249-405-11 CARBON 100 5% 1/4W
R217 1-249-402-11 CARBON 56 5% 1/4W
R218 1-216-022-00 RES-CHIP 75 5% 1/10W
R219 1-216-121-11 RES-CHIP 1M 5% 1/10W
R230 1-216-001-00 RES-CHIP 10 5% 1/10W
R251 1-219-742-11 CARBON 47 5% 1/2W
R261 1-215-394-00 METAL 75 1% 1/4W
R302 1-216-113-00 RES-CHIP 470K 5% 1/10W
R304 1-216-009-91 RES-CHIP 22 5% 1/10W
R306 1-216-673-11 METAL CHIP 8.2K 0.50% 1/10W
R307 1-216-651-11 METAL CHIP 1K 0.50% 1/10W
R308 1-216-674-11 METAL CHIP 9.1K 0.50% 1/10W
R309 1-216-113-00 RES-CHIP 470K 5% 1/10W
R311 1-249-405-11 CARBON 100 5% 1/4W
R317 1-249-402-11 CARBON 56 5% 1/4W
R319 1-216-121-11 RES-CHIP 1M 5% 1/10W
R330 1-216-022-00 RES-CHIP 75 5% 1/10W
R351 1-219-742-11 CARBON 47 5% 1/2W
R361 1-215-394-00 METAL 75 1% 1/4W
SPARK GAP
! SG001 1-519-422-11 GAP, SPARK
! SG002 1-517-499-21 GAP, SPARK
A
