— 37 —
P792
NOTE: The components identifi ed by shading
and ! mark are critical for safety. Replace only
with part number specifi ed.
A component identifi ed by this X symbol indicates that it
has been carefully factory-selected to satisfy regulations
regarding X-ray radiation. Should replacement be required,
replace only with the value originally used.
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
R753 1-216-679-11 METAL CHIP 15K 0.50% 1/10W
R755 1-216-679-11 METAL CHIP 15K 0.50% 1/10W
R902 1-216-295-91 SHORT
R903 1-216-049-11 RES-CHIP 1K 5% 1/10W
R904 1-216-049-11 RES-CHIP 1K 5% 1/10W
R905 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R906 1-216-073-91 RES-CHIP 10K 5% 1/10W
R907 1-260-316-51 CARBON 100 5% 1/2W
R908 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R909 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R910 1-249-411-11 CARBON 330 5% 1/4W
R911 1-249-418-11 CARBON 1.2K 5% 1/4W
R912 1-249-417-11 CARBON 1K 5% 1/4W
R913 1-249-401-11 CARBON 47 5% 1/4W
R914 1-249-401-11 CARBON 47 5% 1/4W
R915 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R916 1-216-077-91 RES-CHIP 15K 5% 1/10W
R917 1-216-077-91 RES-CHIP 15K 5% 1/10W
R918 1-249-417-11 CARBON 1K 5% 1/4W
R919 1-216-073-91 RES-CHIP 10K 5% 1/10W
R920 1-249-421-11 CARBON 2.2K 5% 1/4W
R924 1-216-041-00 RES-CHIP 470 5% 1/10W
R925 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R926 1-216-295-91 SHORT
R929 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R931 1-216-659-11 METAL CHIP 2.2K 0.50% 1/10W
R933 1-249-417-11 CARBON 1K 5% 1/4W
! R934 1-249-429-11 CARBON 10K 5% 1/4W
R935 1-247-807-31 CARBON 100 5% 1/4W
R936 1-247-807-31 CARBON 100 5% 1/4W
R937 1-247-807-31 CARBON 100 5% 1/4W
R938 1-216-025-11 RES-CHIP 100 5% 1/10W
R950 1-216-051-00 RES-CHIP 1.2K 5% 1/10W
R951 1-216-025-11 RES-CHIP 100 5% 1/10W
R957 1-249-401-11 CARBON 47 5% 1/4W
R958 1-249-401-11 CARBON 47 5% 1/4W
R969 1-247-807-31 CARBON 100 5% 1/4W
R971 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R972 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R973 1-216-049-11 RES-CHIP 1K 5% 1/10W
R981 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R982 1-249-413-11 CARBON 470 5% 1/4W
R983 1-216-025-11 RES-CHIP 100 5% 1/10W
R984 1-216-089-91 RES-CHIP 47K 5% 1/10W
R985 1-216-093-91 RES-CHIP 68K 5% 1/10W
VARIABLE RESISTOR
!X RV501 1-241-767-21 RES, ADJ, CERMET 100K
RV502 1-227-387-11 RES, VAR 100
RELAY
! RY601 1-755-067-21 RELAY
SWITCH
! S602 1-554-472-00 SWITCH PUSH (1 KEY)
SPARK GAP
! SG501 1-519-422-11 GAP, SPARK
SG601 1-533-982-21 GAP, SPARK
TRANSFORMER
! T501 1-453-365-21 FBT ASSY NX-4405//VQL4
T503 1-435-975-11 TRANSFORMER, FERRITE (DFT)
T504 1-433-978-11 TRANSFORMER, HORIZONTAL DRIVE
T505 1-435-766-11 TRANSFORMER, FERRITE (HST)
T506 1-435-765-11 TRANSFORMER, FERRITE(LCT)
! T601 1-435-768-11 TRANSFORMER, CONVERTER (SRT)
THERMISTOR
! TH600 1-803-339-11 THERMISTOR, NTC
TH601 1-803-540-11 THERMISTOR, PTC
VARISTOR
! VA601 1-801-073-31 VARISTOR TNR14V471K660
CRYSTAL
X901 1-767-826-21 VIBRATOR, CRYSTAL
X902 1-767-933-11 OSCILLATOR, CERAMIC
H2
* A-1372-991-A H2 MOUNTED PC BOARD
CAPACITOR
C1001 1-130-495-00 MYLAR 0.1µF 5% 50V
C1002 1-102-074-00 CERAMIC 0.001µF 10% 50V
CONNECTOR
* CN1001 1-564-520-11 PLUG,CONNECTOR 5P
DIODE
D1001 8-719-911-19 DIODE 1SS119-25TD
D1002 8-719-911-19 DIODE 1SS119-25TD
D1003 8-719-911-19 DIODE 1SS119-25TD
D1004 8-719-911-19 DIODE 1SS119-25TD
D1005 8-719-081-89 DIODE SML76755WNTP15
H2
D
