3. Remove the 24 screws (M1.2x1.4) that secures the keyboard bracket to the keyboard.

NOTE: Lift the plastic sheet on the keyboard bracket to access the screws.

4. Peel off the tapes that secure the keyboard bracket to the palm-rest assembly.

5. Lift the keyboard bracket off the keyboard.

Removing the keyboard
