Replacing the keyboard
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1. Align the screw holes on the keyboard with the screw holes on the palm-rest assembly.
2. Replace the 19 screws (M1.2x1.5) that secure the keyboard to palm-rest assembly.
3. Align the screws holes on the keyboard bracket with the screw holes on the keyboard.
4. Adhere the tapes that secure the keyboard bracket to the palm-rest assembly.
5. Replace the 24 screws (M1.2x1.4) that secure the keyboard bracket to keyboard.
