Removing the fan
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Topics:
• Prerequisites
• Procedure
Prerequisites
Remove the base cover.
Procedure
1. Disconnect the fan cable from the system board.
2. Remove the two screws (M2x5) that secure the fan to the keyboard bracket.
3. Lift the fan off the keyboard bracket.
13
26 Removing the fan
