Dell PERC S130 - Viewing Virtual Disks Properties and Policies; Deleting the Virtual Disks

Menu Item Description
Virtual Disk
Capacity
Displays the capacity of the virtual disk.
Sector Size Displays the sector size enabled.
Read Cache Policy Displays the read cache policies associated with the virtual disk.
Write Cache Policy Displays the write cache policies associated with the virtual disk.
Physical Disk Write
Cache
Displays the status of the physical disk write cache policy.
Modify the Physical
Disk Write Cache
Enables you to modify the physical disk write cache policy settings.
NOTE: If you have Linux RAID congured on the system then you cannot modify any settings in
this eld.
Physical disk Write
Cache
Enables you to change the physical disk write cache policy settings.
NOTE: If you have Linux RAID congured on the system then you can only view the physical disk
write cache setting.
View Associated
Physical Disk
Clicking this link displays the physical disk that is associated with the specic virtual disk
Viewing virtual disks properties and policies
View Virtual Disk Properties screen allows you to view the virtual disk properties and the policies.
In the System Setup Main Menu, click Device Settings → Dell PERC S130 Conguration Utility → Virtual Disk Management →
View Virtual Disk Properties.
The table explains the View Virtual Disk Properties screen details:
Menu Item
Description
Virtual Disk ID Displays the virtual disk ID.
RAID level Displays the RAID level associated with the virtual disk.
Virtual Disk Status Displays the status of the virtual disk.
Virtual Disk
Capacity
Displays the capacity of the virtual disk.
Sector Size Displays the sector size enabled.
Read Cache Policy Displays the read cache policies associated with the virtual disk
Write Cache Policy Displays the write cache policies associated with the virtual disk
Associated Physical
Disk
Displays the physical disk which is associated with the specic virtual disk
Deleting the virtual disks
1. Enter the Dell PERC S130 Conguration Utility. See Entering the DELL PERC S130 Conguration Utility.
2. Click Virtual Disk Management → Select Virtual Disk Operations.
3. Select a virtual disk that you want to delete from the drop-down menu.
4. Click the link Delete Virtual Disks.
To continue, conrm the option that you selected.
5. Select Conrm and click Yes to continue.
