Dell PERC S130 - Managing the Physical Disk Write Cache Policy; Selecting the 4 Kn Sector Size; Assigning the Global Hot Spare

Managing the physical disk write cache policy
Perform the following procedure to enable the physical disk write cache policy:
1. Enter the Dell PERC S130 Conguration Utility. See Entering the DELL PERC S130 Conguration Utility.
2. Click Physical Disk Management → Select Physical Disk Operations.
3. Click the link Manage Physical Disk Properties.
The Manage Physical Disk Properties screen is displayed.
4. Choose from the following physical disk write cache policies:
Physical disk
write cache
policies
Description
Default The physical disk write cache feature is enabled for:
• SSDs
• 3 Gbps HDDs
The physical disk write cache feature is disabled for 6 Gbps HDDs.
Enable The feature is enabled on the disk selected.
Disable The feature is disabled on the disk selected.
5. Click Apply to save the changes made.
NOTE: Ensure that you change the physical disk write cache policy of a global hot spare disk after rebuild to the
write cache policy of the last congured virtual disk.
NOTE: In the View Virtual Disk Properties screen, ensure that the physical disk write cache setting is consistent
across the physical disk(s) associated with the virtual disk.
NOTE: If you have Linux RAID congured on the system, you cannot modify the physical disk write cache policy
feature settings.
NOTE: For more information about the physical disk write cache behavior, see the Troubleshooting your system
section.
Selecting the 4Kn sector size
1. Enter the Dell PERC S130 Conguration Utility. See Entering the DELL PERC S130 Conguration Utility.
2. Click Virtual Disk Management → Create Virtual Disks.
3. Click the link Select the Physical Disk.
4. Select 4Kn sector size.
5. To save the changes made, click Apply Changes.
Assigning the global hot spare
1. Enter the Dell PERC S130 Conguration Utility. See Entering the DELL PERC S130 Conguration Utility.
2. Click Physical Disk Management → Select Physical Disk Operations.
NOTE: Assign global hot spare only from disk drives populated across slots 0-3 of the system. For information about
the disk connectivity for AHCI devices, see Disk connectivity for AHCI devices,and for disks slot information, see the
system specic Owner's Manual at dell.com/poweredgemanuals.
3. Select the physical disk that is in the ready state from the drop-down menu.
4. Click the link Assign Global Hot Spare.
