Dell POWERCONNECT 5524 User Manual

Getting Started Guide 9
Stacking
Overview
Each switch is a member in a stack, although the stack may consist of only a
single switch. Up to eight switches are supported per stack.
All stacks must have a Master unit, and may have a Master Backup unit. All
other switches are connected to the stack as members (slaves).
Stacking Switches
PowerConnect 5500 series switches use two HDMI 10G ports for stacking.
To connect the switches in the stack:
1
Insert one end of an HDMI cable into the left-hand HDMI port on the
switch at the top of the stack and the other end into the right-hand HDMI
port of the switch immediately below it.
2 Repeat this process until all switches are connected.
3 (Optional) Connect the left-hand HDMI port of the switch at the bottom
of the stack to the right-hand HDMI port of the switch at the top of the
stack. This step provides increased bandwidth and redundancy.
ContaxGS.book Page 9 Friday, August 20, 2010 1:53 PM

Dell POWERCONNECT 5524 Specifications

General

MAC address table	16000 entries
Jumbo frames support	Yes
Packet buffer memory	12 MB
Maximum data transfer rate	10 Gbit/s
Supported data transfer rates	10/100/1000 Mbps
Number of VLANs	4000
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Dimensions (WxDxH)	440 x 255 x 432 mm
Connectivity technology	Wired
Switch type	Managed
Switch layer	L3
SFP/SFP+ slots quantity	2
Basic switching RJ-45 Ethernet ports quantity	24
Memory type	SDRAM
Flash memory	16 MB
Stackable	-
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	3330 g
