Installing System Components 109
5
Replace the sideplane. See "Installing the Sideplane Board" on page 102
6
Reinstall the TOE key, if applicable. See Figure 6-2 for the TOE key’s location.
7
Replace the heatsink(s) and microprocessor(s). See "Installing a Processor" on page 95.
8
Replace the memory modules. See "Installing Memory Modules" on page 90.
9
If applicable, replace the RAC card. See "Installing a RAC Card" on page 80.
10
Replace the fan bracket. See "Replacing the Fan Bracket" on page 69.
11
Replace the fans. See "Replacing a Cooling Fan" on page 66.
12
Replace the cooling shroud. See "Installing the Cooling Shroud" on page 67.
13
Replace the expansion-card cage. See "Replacing the Expansion-Card Cage" on page 79.
14
If applicable, replace any expansion cards. See "Installing an Expansion Card" on page 76.
15
Close the system. See "Closing the System" on page 55.
Book.book Page 109 Friday, February 3, 2006 11:09 AM
