140 Jumpers and Connectors
Figure 6-4. SAS Backplane Board Components: 3.5-inch x4 Option
5
7
front
back
3
2
1
6
4
1 drive 0 (SASDRV0) 2 SAS (SAS_A) 3 tape drive power connector
(J_TBU_PWR)
4 drive 2 (SASDRV2) 5 drive 3 (SASDRV3) 6 drive 1 (SASDRV1)
7 backplane power
(J_BP_PWR)
