Installing System Components 71
Figure 3-12. Installing a SAS Controller Daughter Card
6
Attach any cables from the SAS controller daughter card to the backplane, referring to Figure 3-13,
Figure 3-14, Figure 3-15, or Figure 3-16 for the cabling guidelines for your system’s card and backplane
configuration.
1 SAS controller daughter card 2 SAS controller daughter card
slot
3 release tab
4 SAS controller daughter card
battery connector
5 SAS connectors 0 and 1 (for
RAID card only) out to
backplane SAS_A or SAS_B
(for RAID card only) connector
6 chassis slots (2)
7 SAS controller daughter card
tray
1
2
5
4
3
6
7
