Installing System Components 73
Figure 3-15. SAS RAID Controller Daughter Card Cabling With 3.5-inch x4 Backplane
Figure 3-16. SAS RAID Controller Daughter Card Cabling With 2.5-inch x8 Backplane
1 SAS controller 0 2 SAS RAID controller daughter
card
3 SAS controller 1
4 SAS backplane A 5 3.5-inch x4 backplane
1 SAS controller 0 2 SAS RAID controller daughter
card
3 SAS backplane A
4 SAS controller 1 5 SAS backplane B 6 2.5-inch x8 backplane
2
5
4
1
3
2
6
5
4
1
3
