Dell PowerEdge C6220 II Technical Guide

12 PowerEdge C6220 II Technical Guide
Figure 3. Back view with four server nodes
Chassis features
Table 4 lists the features on the PowerEdge C6220 II chassis. For additional information on
PowerEdge C6220 II chassis features, see the Dell PowerEdge C6220 II Systems Hardware Owner’s
Manual on Dell.com/Support/Manuals.
Table 4. Chassis features
Feature
Description
Power-on indicator and
power button
ACPI-complaint power button with an integrated green power LED
System identification
indicator/button
Buttons on the back and front of a system to help identify the unit in a
data center environment
USB connectors
2 on the back panel
Hard drives
Up to 12 x 3.5-inch hot-plug hard drives
Up to 24 x 2.5-inch hot-plug hard drives
Hard drive activity LEDs
Indicate the status and activity of the hard drives
Optical drive (optional)
Supports optional DVD drives; see the Storage section
Drive cover
Applicable for 2.5-inch hard drive systems only
Power supply units
Up to 2 back-accessible, hot-plug power supplies
Power supply indicators
Indicates whether system has power
NIC indicators
Indicates network activity and status
Ethernet connectors
Choice of network connectors through the Select Network Adapter
family
Serial connector
Connects a serial device to the system

Dell PowerEdge C6220 II Specifications

General

Form Factor	2U Rack
Processor	Intel Xeon E5-2600 v2 series
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
Memory	Up to 512GB DDR3 per node
Storage	Up to 24 x 2.5" hot-plug SAS, SATA, or SSD drives
Network	Dual 1GbE, optional 10GbE
Management	Dell Remote Access Controller (iDRAC7) with Lifecycle Controller
Number of Processors	Up to 2 per node (4 total in 2U chassis)
Power Supply	Redundant hot-plug power supplies
