Dell PowerEdge C6220 II Technical Guide

8 PowerEdge C6220 II Technical Guide
Table 3. Technical specifications
Feature
PowerEdge C6220 II technical specification
Form factor
2U rack mount chassis supporting 1 to 4 independent server nodes
Sled types
1U or 2U PowerEdge C6220 II sleds
Maximum of 4 1U or 2 2U PowerEdge C6220 II sleds in a chassis
Processors
Intel Xeon processor E5-2600 v2 product family
Processor sockets
2 sockets (up to 4x 2-socket servers)
Internal interconnect
2 Intel QPI links: 6.4GT/s, 7.2GT/s, 8.0GT/s
Cache
Up to 30MB with L3 cache; core options: 2, 4, 6, 8, 10 or 12 cores
Chipset
Intel C602
Memory
1
16 DIMM slots, up to 512GB per node:
4GB/8GB/16GB (1.5V) DDR3 RDIMM (1866MT/s)
4GB/8GB/16GB LV (1.35V) DDR3 RDIMM (1600MT/s)
32GB LV DDR3 RDIMM (1333MT/s)
4GB LV DDR3 UDIMM (1600MT/s)
32GB LV DDR3 LRDIMM (1600MT/s)
I/O slots
1U sled:
1 x16 PCIe 3.0 half-height (low
profile), half-length riser slot
1 x8 PCIe 3.0 daughtercard
(mezzanine) connector
2U sled:
1 x16 PCIe 3.0 full height, full length
riser slot
1 x16 PCIe 3.0 full height, half-length riser
slot
1 x8 PCIe 3.0 daughtercard (mezzanine)
connector
Drive controller
Intel C602: SATA or SSDs only
RAID controller
LSI 2008 6Gbps SAS mezzanine (optional)
LSI 9210-8i 6Gbps SAS add-in controller (optional)
LSI 9265-8i 6Gbps SAS add-in controller (optional)
Hard drives
(hot-plug)
Drive bay options:
Up to 24 x 2.5” or up to 12 x 3.5”
Hard drive options:
2.5” SAS (15K): 146GB, 300GB
2.5” SAS (10K): 600GB, 900GB, 1.2TB
2.5” SATA: 500GB, 1TB
2.5” NL SAS (7.2K): 1TB
2.5” SATA SSD (eMLC): 100GB, 200GB,
400GB, 800GB
2.5” SATA SSD (MLC): 120GB, 160GB,
240GB, 300GB, 480GB, 800GB
3.5” SATA (7.2K): 1TB, 2TB, 3TB, 4TB
3.5” SAS (15K): 600GB
3.5” NL SAS (7.2K): 1TB, 2TB, 3TB, 4TB
Embedded Network
Adapter
Intel I350 2 x 1GbE

Dell PowerEdge C6220 II Specifications

General

Form Factor	2U Rack
Processor	Intel Xeon E5-2600 v2 series
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
Memory	Up to 512GB DDR3 per node
Storage	Up to 24 x 2.5" hot-plug SAS, SATA, or SSD drives
Network	Dual 1GbE, optional 10GbE
Management	Dell Remote Access Controller (iDRAC7) with Lifecycle Controller
Number of Processors	Up to 2 per node (4 total in 2U chassis)
Power Supply	Redundant hot-plug power supplies
