Dell PowerEdge C6220 II - RAID Configurations; Storage Controllers; Table 9. RAID Support

21 PowerEdge C6220 II Technical Guide
Form
factor
Type
Speed
(rpm)
Capacities
Nearline SAS (6Gb)
7.2K
1TB, 2TB, 3TB, 4TB
2.5”
SATA (3Gb)
7.2K
500GB, 1TB
SAS (6Gb)
10K
600GB, 900GB, 1.2TB
SAS (6Gb)
15K
146GB, 300GB
Nearline SAS (6Gb)
7.2K
1TB
SATA SSD (MLC)
NA
120GB, 160GB, 240GB, 300GB,
480GB, 800GB
SATA SSD (eMLC)
NA
100GB, 200GB, 400GB, 800GB
RAID configurations
The PowerEdge C6220 II supports RAID configurations, but only as a user-configurable option. See
the available RAID options listed in Table 9.
Table 9. RAID support
Controller
Supported RAID levels
Embedded Intel C602 chipset-based SATA
RAID 0, 1, 10, 5
LSI 2008 mezzanine at 6Gbps
RAID 0, 1, 10, JBOD
LSI MegaRAID SAS 9265-8i at 6Gbps
RAID 0, 1, 5, 6, 10, 50, 60
LSI SAS 9210-8i at 6Gbps
RAID 0, 1, 1E, 10, JBOD
Dell MegaRAID SAS 9285-8e (only available via customer kit)
RAID 0, 1, 5, 6, 10, 50, 60
Storage controllers
Onboard controller
The Intel C602 chipset includes the embedded. The PowerEdge C6220 II uses the –J variant of the
C602. For more information, visit Intel.com.
 Storage controller: Intel AHCI SATA
 Supported protocols: SATA only
 Cache: None
 Battery: None
 RAID level: RAID 0, 1, 5
 RAID spans: 10
 Device Type: Onboard controller
 PCI Interface: x4 DMI
 Ports: 6
