About Your System 11
Front-Panel Features and Indicators
Figure 1-1 shows the controls, indicators, and connectors located on the
system's front panel. Table 1-2 provides component descriptions.
Figure 1-1. Front-Panel Features and Indicators
Table 1-2. Front-Panel Components
Item Component Icon Description
1 USB connectors (2) Connects USB 2.0-compliant
devices to the system.
book.book Page 11 Wednesday, June 24, 2009 8:21 AM
