Installing System Components 57
16
(Optional) Test the drive by running the system diagnostics. See "Running
the System Diagnostics" on page 131.
Optical and Tape Drives
In the upper 5.25-inch drive bay, you can install only an optical drive. In the
lower 5.25-inch drive bay, you can install either an optical or a tape backup
unit.
Removing an Optical or Tape Drive
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not covered
by your warranty. Read and follow the safety instructions that came with the
product.
1
Turn off the system and attached peripherals, and disconnect the system
from the electrical outlet.
2
Open the system. See "Opening the System" on page 47.
3
Remove the front drive bezel. See "Removing the Front Drive Bezel" on
page 49.
4
Disconnect the power and data cables from the back of the drive. See
Figure 3-9 for disconnecting SCSI connections and Figure 3-10 for
disconnecting SATA connections.
5
Slide the lever on the sliding plate in the direction of the arrow to release
the shoulder screw.
6
Slide the drive out to remove it from the drive bay.
book.book Page 57 Wednesday, June 24, 2009 8:21 AM
