D.2 Half-width servers with dual-port CNAs
The PowerEdge FC630 is an example of a half-width server. For half-width servers with dual-port CNAs
installed, the CNA ports map to a single port on each of the two FN IOMs. Figure 12 and Table 2 present the
port mapping for half-width servers with dual-port CNAs.
Note: Ports 2, 4, 6 and 8 are not used when using half-width blades with dual-port adapters.
Half-width servers with dual-port CNAs
Half-width servers with dual-port CNAs
Server Slot
FN IOM A1 (Top)
Internal Port Numbers
FN IOM A2 (Bottom)
Internal Port Numbers
1
1
1
2
3
3
3
5
5
4
7
7
Slot 2
Slot 3 Slot 4
FN IOM A1 (Top)
Internal Ports
5 6
3
7
4
8
21
FN IOM A2 (Bottom)
Internal Ports
5 6
3
7
4
8
1
Slot 1
2
