D.4 Full-width servers with dual-port CNAs
The PowerEdge FC830 is an example of a full-width server. For full-width servers with dual-port CNAs
installed, the CNA ports map to two ports on each FN IOM. Figure 14 and Table 4 present the port mapping
for full-width servers with dual-port CNAs.
FN IOM A1 (Top)
Internal Ports
5 6
3
7
4
8
21
FN IOM A2 (Bottom)
Internal Ports
5
6
3
7
4
8
0 1 2 3
SAS/ SATA
0 1 2 3
SAS/ SATA
Slot 1
Slot 3
21
Full-width servers with dual-port CNAs
Full-width servers with dual-port CNAs
Server Slot
FN IOM A1 (Top)
Internal Port Numbers
FN IOM A2 (Bottom)
Internal Port Numbers
1
1 , 3
1 , 3
3
5 , 7
5 , 7
