21 PowerEdge FX2 - Upgrading from 10GbE Pass-through Modules to FN410S I/O Modules | version 1.0
D.3 Half-width servers with quad-port CNAs
For half-width servers with quad-port CNAs installed, the CNA ports map to two ports on each FN IOM. Figure
13 and Table 3 present the port mapping for half-width servers with quad-port CNAs.
Slot 2
Slot 3 Slot 4
FN IOM A1 (Top)
Internal Ports
5 6
3
7
4
8
21
FN IOM A2 (Bottom)
Internal Ports
5 6
3
7
4
8
1
Slot 1
2
Half-width servers with quad-port CNAs
Half-width servers with quad-port CNAs
Server Slot
FN IOM A1 (Top)
Internal Port Numbers
FN IOM A2 (Bottom)
Internal Port Numbers
1
1,2
1,2
2
3,4
3,4
3
5,6
5,6
4
7,8
7,8
