D.5 Full-width Servers with quad-port CNAs
For full-width servers with quad-port CNAs installed, the CNA ports map to four ports on each FN IOM. Figure
15 and Table 5 present the port mapping for full-width servers with quad-port CNAs.
FN IOM A1 (Top)
Internal Ports
5 6
3
7
4
8
21
FN IOM A2 (Bottom)
Internal Ports
5 6
3
7
4
8
0 1 2 3
SAS/ SATA
0 1 2 3
SAS/ SATA
Slot 1
Slot 3
21
Full-width servers with quad-port CNAs
Full-width servers with quad-port CNAs
Server Slot
FN IOM A1 (Top)
Internal Port Numbers
FN IOM A2 (Bottom)
Internal Port Numbers
1
1 , 2 , 3 , 4
1 , 2 , 3 , 4
3
5 , 6 , 7 , 8
5 , 6 , 7 , 8
