System capacity
(in GB)
DIMM size (in
GB)
Number of
DIMMs
Organization and
speed
DIMM slot population
64 8 8
1R x8, 2400 MT/s
A1, A2, A3, A4, B1, B2, B3,
B4
64 8 8
2R x8, 2133 MT/s
A1, A2, A3, A4, B1, B2, B3,
B4
96 4 24
1R x8, 2133 MT/s
A1, A2, A3, A4, A5, A6, A7,
A8, A9, A10, A11, A12, B1,
B2, B3, B4, B5, B6, B7, B8,
B9, B10, B11, B12
96 8 12
2R x8, 2133 MT/s
A1, A2, A3, A4, A5, A6, B1,
B2, B3, B4, B5, B6
128 8 16
1R x8, 2133 MT/s
A1, A2, A3, A4, A5, A6, A7,
A8, B1, B2, B3, B4, B5, B6,
B7, B8
128 16 8
2R x4, 2133 MT/s
A1, A2, A3, A4, B1, B2, B3,
B4
128 16 8
2R x8, 2400 MT/s
A1, A2, A3, A4, B1, B2, B3,
B4
160 8 20
2R x8, 2133 MT/s
A1, A2, A3, A4, A5, A6, A7,
A8, A9, A10, B1, B2, B3,
B4, B5, B6, B7, B8, B9, B10
160 16 and 8 12
2R x4, 2133 MT/s
2R x8, 2133 MT/s
A1, A2, A3, A4, A5, A6, B1,
B2, B3, B4, B5, B6
NOTE: 16 GB DIMMs
must be installed in
the slots numbered
A1, A2, A3, A4, B1, B2,
B3, and B4 and 8 GB
DIMMs must be
installed in slots A5,
A6, B5 and B6.
192 8 24
1R x8, 2133 MT/s
A1, A2, A3, A4, A5, A6, A7,
A8, A9, A10, A11, A12, B1,
B2, B3, B4, B5, B6, B7, B8,
B9, B10, B11, B12
192 16 12
2R x4, 2133 MT/s
A1, A2, A3, A4, A5, A6, B1,
B2, B3, B4, B5, B6
256 16 16
2R x4, 2133 MT/s
A1, A2, A3, A4, A5, A6, A7,
A8, B1, B2, B3, B4, B5, B6,
B7, B8
384 16 24
2R x4, 2133 MT/s
A1, A2, A3, A4, A5, A6, A7,
A8, A9, A10, A11, A12, B1,
