Page 40 (13 Video)
Dell PowerEdge R210 II - 13 Video; Table 16. Graphics Video Modes
57 pages
Manual
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
Dell
40
PowerEdge R210 II Te
chnical Guide
13
Video
The PowerEd
ge R210 II includes a Matrox
®
G200eW with 8 MB m
emory integrated
in Winbond
®
WPCM450 (BMC
controller).
The resolutio
ns supported are listed
in Table 16.
Table 16.
Graphics Video
Modes
Resolution
Refresh Rate (Hz)
Color Depth
(bit)
640 x 480
60, 72, 75, 85
8, 16, 32
800 x 600
60, 72, 75, 85
8, 16, 32
1024 x 768
60, 70, 75, 85
8, 16, 32
1280 x 102
4
60, 75, 85
8, 16
1280 x 102
4
60
32
39
41
