Dell PowerEdge R730xd User Manual

Troubleshooting iDRAC Direct (USB XML configuration)
For information about USB storage device and server configuration, see the Integrated Dell Remote
Access Controller User's Guide at Dell.com/idracmanuals.
Steps
1. Ensure that your USB storage device is connected to the front USB Management Port, identified by
icon.
2. Ensure that your USB storage device is configured with an NTFS or an FAT32 file system with only
one partition.
3. Verify that the USB storage device is configured correctly. For more information about configuring
the USB storage device, see the Integrated Dell Remote Access Controller User's Guide at Dell.com/
idracmanuals.
4. In the iDRAC Settings Utility, ensure that USB Management Port Mode is configured as Automatic
or iDRAC Direct Only.
5. Ensure that the iDRAC Managed: USB XML Configuration option is either Enabled or Enabled only
when the server has default credential settings.
6. Remove and reinsert the USB storage device.
7. If import operation does not work, try with a different USB storage device.
Next steps
If all troubleshooting fails, see the Getting help section.
Related Links
Getting help
Troubleshooting iDRAC Direct (Laptop connection)
For information about USB laptop connection and server configuration, see the Integrated Dell Remote
Access Controller User's Guide at Dell.com/idracmanuals.
Steps
1. Ensure that your laptop is connected to the front USB Management Port, identified by icon with
a USB Type A/A cable.
2. On the iDRAC Settings Utility screen, ensure that USB Management Port Mode is configured as
Automatic or iDRAC Direct Only.
3. If the laptop is running Windows operating system, ensure that the iDRAC Virtual USB NIC device
driver is installed.
4. If the driver is installed, ensure that you are not connected to any network through WiFi or cabled
ethernet, as iDRAC Direct uses a non-routable address.
Next steps
If all troubleshooting fails, see the Getting help section.
Related Links
Getting help
225

Dell PowerEdge R730xd Specifications

General

Tcase	72.6 °C
Bus type	QPI
Stepping	R2
FSB Parity	No
Scalability	2S
Processor code	SR207
Processor cache	15 MB
Processor cores	6
Processor model	E5-2620V3
System bus rate	8 GT/s
Processor series	Intel Xeon E5-2600 v3
Processor socket	LGA 2011-v3
Processor threads	12
Processor codename	Haswell
Motherboard chipset	Intel C610
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	52.5 x 45 mm
Processor front side bus	- MHz
Processor boost frequency	3.2 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX
Thermal Design Power (TDP)	85 W
Number of processors installed	1
Maximum number of SMP processors	2
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	1600, 1866 MHz
Memory bandwidth supported by processor (max)	59 GB/s
Maximum internal memory supported by processor	768 GB
HDD size	3.5 \
HDD speed	7200 RPM
RAID levels	0, 1, 5, 6
HDD interface	Serial ATA, Serial Attached SCSI (SAS)
Total storage capacity	4000 GB
Maximum storage capacity	99.6 TB
Supported storage drive interfaces	Serial ATA
Memory slots	24
Internal memory	16 GB
Memory clock speed	2133 MHz
LAN controller	Broadcom 5720
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	4
Operating system installed	-
Compatible operating systems	Microsoft Windows Server 2008/2012 SP2, x86/x64 (x64 includes Hyper-VTM )\\r Microsoft Windows Server 2008/2012 R2, x64 (includes Hyper-VTM v2)\\r Microsoft Windows HPC Server 2008\\r Novell SUSE Linux Enterprise Server\\r Red Hat Enterprise Linux\\r VMware ESX
Chassis type	Rack (2U)
Power supply	750 W
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
Processor ARK ID	83352
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
PCI Express slots version	3.0
On-board graphics card model	Not available

Weight and Dimensions

Depth	684 mm
Width	440 mm
Height	87.3 mm
