142 Installing System Components
10 Reconnect your system and peripherals to their electrical outlets, and turn
on the system.
Figure 3-26. Removing and Installing a FlexMem Bridge
1 FlexMem Bridge 2 notch in FlexMem Bridge
3 socket key (2) 4 processor shield
5 ZIF socket 6 socket-release lever
1
5
4
2
3
6
