Dell PowerEdge R810 - Power Distribution Board Connectors

190 Jumpers and Connectors
Power Distribution Board Connectors
Figure 6-3. Power Distribution Board Connectors
1 power supply connectors (2) 2 12-pin power cable connector
3 mixed signal connector
3
1
2
