Dell PowerEdge R810 - Installing a Power Supply

Installing System Components 95
Figure 3-8. Removing and Installing a Power Supply
Installing a Power Supply
1 Verify that the power supplies are of the same type and have the same
maximum output power.
NOTE: The maximum output power (shown in watts) is listed on the power
supply label.
2 If applicable, remove the power supply blank. See "Removing the Power
Supply Blank" on page 96.
1 power supply 2 power supply handle
3 velcro strap 4 release tab
1
2
3
4
