Dell PowerEdge R830 - Processor Specifications; PSU Specifications; System Battery Specifications; Expansion Bus Specifications

Processor specications
The PowerEdge R830 system supports up to four Intel Xeon E5-4600 v4 product family processors.
PSU specications
The PowerEdge R830 system supports up to two AC redundant power supply units (PSU).
Table 11. PSU specications
PSU Class Heat dissipation
(maximum)
Frequency Voltage
750 W AC Platinum 50/60 Hz 100–240 V AC, autoranging
1600 W AC Platinum 100–240 V AC, autoranging
NOTE: If a system with 1600 W PSUs
operates from 100 to 120 V, then the
power rating per PSU is derated to 800
W.
NOTE: Heat dissipation is calculated using the PSU wattage rating.
NOTE: This system is also designed to connect to the IT power systems with a phase to phase voltage not exceeding 230
V.
System battery specications
The PowerEdge R830 system supports CR 2032 3.0-V lithium coin cell system battery.
Expansion bus specications
The PowerEdge R830 system supports PCI express (PCIe) generation 3 expansion cards, which need to be installed on the system
board using expansion card risers. This system supports three types of expansion card risers.
Memory specications
The PowerEdge R830 system supports DDR4 registered DIMMs (RDIMMs) and load-reduced DIMMs (LRDIMMs).
Table 12. Memory specications
Memory module sockets Memory capacity Minimum RAM Maximum RAM
Forty-eight DIMM sockets
• 64 GB or 128 GB quad rank
(LRDIMMs)
• 8 GB single rank (RDIMMs)
• 16 GB or 32 GB dual rank
(RDIMMs)
8 GB with dual processors
(minimum one memory module
per processor)
LRDIMM up to 6144 GB with
four processors
Drive specications
Hard drives
The PowerEdge R830 system supports SAS, SATA, or Nearline SAS hard drives.
23
