10 About Your Enclosure
Item Indicator, Button, or
Connector
Icon Description
1 Enclosure status LED The enclosure status LED lights when
the enclosure power is on.
Lights blue during normal operation and
when the host server is identifying
the enclosure.
Blinks blue when a host server is
identifying the enclosure or when the
system identification button is pressed.
Lights amber when the enclosure is
turned on or is reset.
Blinks amber when the enclosure is in
the fault state.
2 Power LED The power LED lights when at least one
power supply is supplying power to
the enclosure.
3 Split mode LED The split mode LED lights when
the enclosure is in a split-mode
configuration.
If the LED is not lit, it indicates that
the enclosure is in a unified-mode
configuration.
