Management: Installing Array Components 233

Figure 16-16. Removing and Installing the Backplane-PowerVault MD3200i

Figure 16-17. Removing and Installing the Backplane-PowerVault MD3220i

1 screws (5) 2 backplane

3 captive screw

1 screws (4) 2 backplane

3 captive screw

book.book Page 233 Saturday, September 24, 2011 9:06 AM
