Appendix 107
Battery
Type 9-cell, 80-WHr, "smart" lithium ion
Dimensions:
Depth
88.5 mm (3.48 inches)
Height
21.5 mm (0.83 inch)
Width
139.0 mm (5.47 inches)
Weight 474 grams (1.04 lb) (9 cell)
Voltage 10.8 VDC
Charge time (approximate)
:
Computer off
2 hours (at 80% in 2 hours)
Operating time Battery operating time varies depending on
operating conditions and can be significantly
reduced under certain power-intensive
conditions. See "Power Problems" on
page 71.
See "Using a Battery" on page 31 for more
information on battery life and operating
time.
Life span (approximate) 500 discharge/charge cycles
Temperature range:
Operating
0° to 35°C (32° to 95°F)
Storage
–40° to 65°C (–40° to 149°F)
AC Adapter
Input voltage 90–265 VAC
Input current (maximum) 2.5 A
Input frequency 47–63 Hz
Output current 6.7 A
Output power 130 W
Rated output voltage 19.5 VDC
