Adding and Replacing Parts 97
5
Install the replacement battery:
a
Insert the battery at a 30-degree angle under the latch release with the positive side up,
and then push the battery into place.
b
Connect the battery cable to the connector on the system board.
6
Replace the keyboard.
7
Replace the hinge cover.
Display
CAUTION: Before you begin any of the procedures in this section, follow the safety instructions in the
Product Information Guide.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by
periodically touching an unpainted metal surface (such as a connector on the back of the computer).
NOTICE: To avoid damaging the system board, you must remove the main battery before you begin
working inside the computer.
1
Follow the procedures in "Before You Begin" on page 83.
2
Loosen the two captive screws and remove the Mini PCI card cover.
coin-cell battery
release latch
battery cable connector
