44 Using CDs, DVDs, and Other Multimedia
www.dell.com | support.dell.com
1
Turn off the computer and the TV and/or audio device that you want to connect.
2
Connect the TV/digital audio adapter cable to the S-video TV-out connector on the
computer.
3
Plug one end of the composite video cable in to the composite video-input connector on the
TV/digital audio adapter cable.
4
Plug the other end of the composite video cable in to the composite video-input connector on
the TV.
5
Plug one end of the S/PDIF digital audio cable in to the S/PDIF audio connector on the
TV/digital audio adapter cable.
6
Plug the other end of the digital audio cable in to the S/PDIF input connector on your TV or
other audio device.
composite
video cable
TV/digital audio
adapter cable
standard
audio cable
