Dell Precision 3930 Rack - Expansion Card

4 Install the:
a Power supply unit
b Top cover
5 Follow the procedure in After working inside your computer.
Expansion card
Riser 1 module
Removing riser1 module
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a Top cover
3 To remove the riser1 module:
a Holding the two blue lift points and pull the riser1 module from the slot.
Removing and installing components
59
