3 Install the:
a Riser 1 module
b Top cover
4 Follow the procedure in After working inside your computer.
Removing the riser 1 dell ultra-speed drive duo card
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a Top cover
b Riser 1 module
3 Removing the riser 1 dell ultra-speed drive duo card:
a Pull the release tab [1] and open the riser 1 slot.
b Push the release tab on the PCIe slot [2], lift out the Dell Ultra-speed Drive Duo Card from slot [3].
Removing and installing components
65
