Dell Precision Rack 7910 User Manual

Drive-status indicator pattern (RAID only) Condition
Blinks green two times per second Identifying drive or preparing for removal.
Off Drive ready for insertion or removal.
NOTE: The drive status indicator remains off until
all hard drives are initialized after the system is
turned on. Drives are not ready for insertion or
removal during this time.
Blinks green, amber, and turns off Predicted drive failure
Blinks amber four times per second Drive failed
Blinks green slowly Drive rebuilding
Steady green Drive online
Blinks green three seconds, amber three
seconds, and turns off six seconds
Rebuild aborted
13

Dell Precision Rack 7910 Specifications

General

Chipset	Intel C612
Form Factor	2U Rack
Processor Options	Intel Xeon processor E5-2600 v4 product family
Storage Options	SATA, SAS
Graphics	NVIDIA Quadro or AMD FirePro
Power Supply	1100W
Network	Integrated Intel Gigabit Ethernet
Operating System	Red Hat Enterprise Linux, Ubuntu
