Dell Precision Rack 7910 User Manual

Item Indicator, Button, or
Connector
Icon Description
17 Serial connector Allows you to connect a serial device to the
system.
18 Video connector Allows you to connect a VGA display to the
system.
19 USB connector (2) Allows you to connect USB devices to the system.
The ports are USB 2.0-compliant.
20 Full-height PCIe
expansion card slot (4)
Allows you to connect up to four single wall or
two double wide PCI Express expansion cards.
21 Ethernet connector (4) Four integrated 10/100/1000 Mbps NIC
connectors
or
Four integrated connectors that include:
• Two 10/100/1000 Mbps NIC connectors
• Two 100 Mbps/1 Gbps/10 Gbps NIC
connectors
22 Power supply unit
AC 1100 W
Front bezel (optional)
Removing the front bezel
1. Unlock the bezel lock at the left end of the bezel.
2. Lift the release latch next to the bezel lock.
3. Pull the left end of the bezel, unhook the right end and remove the bezel.
18

Dell Precision Rack 7910 Specifications

General

Chipset	Intel C612
Form Factor	2U Rack
Processor Options	Intel Xeon processor E5-2600 v4 product family
Storage Options	SATA, SAS
Graphics	NVIDIA Quadro or AMD FirePro
Power Supply	1100W
Network	Integrated Intel Gigabit Ethernet
Operating System	Red Hat Enterprise Linux, Ubuntu
