Dell Precision Rack 7910 User Manual

2. control-panel board
3. control-panel connector cable
4. USB connector cable
Figure 44. Removing and installing the control panel—2.5 inch hard-drive system—PowerEdge R730
1. control panel 2. control-panel board
3. control-panel connector cable 4. USB connector cable
5. screw (2) 6. vFlash media connector cable
4. Locate and press the tabs on the information tag.
5. Push the information tag out of the slot to remove it from the control panel.
NOTE: Retain the information tag for replacement in the new control panel.
90

Dell Precision Rack 7910 Specifications

General

Chipset	Intel C612
Form Factor	2U Rack
Processor Options	Intel Xeon processor E5-2600 v4 product family
Storage Options	SATA, SAS
Graphics	NVIDIA Quadro or AMD FirePro
Power Supply	1100W
Network	Integrated Intel Gigabit Ethernet
Operating System	Red Hat Enterprise Linux, Ubuntu
