Dell S2721DS User Manual

Setting up the monitor  │  31
Connecting the stand - S2721QS
NOTE: The stand is not factory-installed.
NOTE: The following instructions are applicable only for attaching the
stand that was shipped with your monitor. If you are attaching a stand
that you purchased from any other source, follow the set up
instructions that were included with the stand.
To attach the monitor stand:
1. Follow the instructions on the flaps of packaging box to remove the stand
from the top cushion that secures it.
2. Remove the stand base and stand riser from the packaging cushion.
3. Align and place the stand riser on the stand base.
4. Open the screw handle at the bottom of the stand base and turn it clockwise
to secure the stand assembly.
5. Close the screw handle.

Dell S2721DS Specifications

General

Pixel pitch	0.2331 x 0.2331 mm
Screen shape	Flat
Pixel density	108.79 ppi
Backlight type	W-LED
Display diagonal	27 \
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	48 - 75 Hz
Maximum refresh rate	75 Hz
Response time (fast)	5 ms
Horizontal scan range	30 - 115 kHz
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
NTSC coverage (typical)	72 %
sRGB coverage (typical)	99 %
Display number of colors	16.78 million colors
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1600 x 900, 1920 x 1080 (HD 1080), 2560 x 1440
RMS rated power	6 W
Number of speakers	2
Product color	Gray
Front bezel color	Black
Heavy metals free	Hg (mercury)
Market positioning	Business
Sustainability certificates	RoHS, ENERGY STAR
HDMI version	1.4
DisplayPort version	1.2
Pivot angle	-90 - 90 °
LED indicators	Power
Tilt angle range	-5 - 21 °
Panel mounting interface	100 x 100 mm
Input current	1.5 A
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	40 W
Annual energy consumption	29 kWh
Power consumption (standby)	0.2 W
Power consumption (typical)	19 W
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Package depth	819.91 mm
Package width	139.95 mm
Package height	446.79 mm
Package weight	8900 g
Cables included	AC, HDMI
Harmonized System (HS) code	85285210
Ethernet LAN (RJ-45) ports	0

Weight and Dimensions

Bezel width (side)	7.4 mm
Depth (with stand)	174.7 mm
Height (with stand)	510.1 mm
Weight (with stand)	6200 g
Bezel width (bottom)	21.6 mm
Depth (without stand)	55.4 mm
Width (without stand)	611.6 mm
Height (without stand)	364.6 mm
Weight (without stand)	4400 g
