32 Dell EMC Networking with Isilon Front-End Deployment and Best Practices Guide | version 1.0
6.3 Configuration of S4048-ON OS9 Leaf Switches
Configurations in this section cover leaf switches 3 and 4 running OS9 as seen in Figure 20.
OS9 Leaf pair
The ports for additional Isilon nodes and servers in this example can be found in the following table:
Interface enumeration
Server/Isilon Node
Switch
Leaf interface
Node 01-4
Leaf 3
tengigabitethernet 1/1/1
Leaf 4
tengigabitethernet 1/1/1

Dell S3048-ON Specifications

General

Rack Units	1U
Form Factor	Rack-mountable
Input Voltage	100-240V AC
Power Supply	2 hot-swappable power supplies
Management	CLI, Web, SNMP
Product Type	Switch
MAC Address Table Size	32K entries
Jumbo Frame Support	Yes
Latency	< 3 microseconds
Ports	48 x 1GbE RJ45, 4 x 10GbE SFP+
