66 Dell EMC Networking with Isilon Front-End Deployment and Best Practices Guide | version 1.0
S4048-Leaf3#show spanning-tree rstp brief
Executing IEEE compatible Spanning Tree Protocol
Root ID Priority 0, Address f48e.382e.a0f7
Root Bridge hello time 2, max age 20, forward delay 15
Bridge ID Priority 0, Address f48e.382e.a0f7
We are the root
Configured hello time 2, max age 20, forward delay 15
Interface Designated
Name PortID Prio Cost Sts Cost Bridge ID PortID
---------- -------- ---- ----- ----------- ------- -------------------- --------
Po 1 128.2 128 1800 FWD(vlt) 0 0 f48e.382e.a0f7 128.2
Po 3 128.4 128 1800 FWD(vlt) 0 0 f48e.382e.a0f7 128.4
Po 5 128.6 128 1800 FWD(vlt) 0 0 f48e.382e.a0f7 128.6
Po 101 128.102 128 1800 FWD(vlt) 0 0 f48e.382e.a0f7 128.102
Po 102 128.103 128 1800 FWD(vlt) 0 0 f48e.382e.a0f7 128.103
Po 128 128.129 128 600 FWD(vltI) 0 0 f48e.382e.a0f7 128.129
Interface
Name Role PortID Prio Cost Sts Cost Link-type Edge
---------- ------ -------- ---- ------- ----------- ------- --------- ----
Po 1 Desg 128.2 128 1800 FWD 0 (vlt) P2P Yes
Po 3 Desg 128.4 128 1800 FWD 0 (vlt) P2P Yes
Po 5 Desq 128.6 128 1800 FWD 0 (vlt) P2P Yes
Po 101 Desg 128.102 128 1800 FWD 0 (vlt) P2P Yes
Po 102 Desg 128.103 128 1800 FWD 0 (vlt) P2P Yes
Po 128 Desg 128.129 128 600 FWD 0 (vltI)P2P No
8.2.8 Show vrrp brief
This command is used to verify that VRRP is correctly configured and both switches in the VLT have the
same virtual address.
S4048-Leaf3#show vrrp brief
Interface Group Pri Pre State Master addr Virtual addr(s)
Description
--------------------------------------------------------------------------------
Vl 200 IPv4 200 150 Y Master 172.16.2.252 172.16.2.254
