S4048-Leaf1 has two paths to all other leafs and two paths to Server 3’s network, 172.16.2.0. There is one
path through each spine. If all paths do not appear, make sure the maximum-paths statement in the BGP
configuration is equal to or greater than the number of spines in the topology.
Z9100-Spine1# show ip route bgp
Codes: C - connected
S - static
B - BGP, IN - internal BGP, EX - external BGP
O - OSPF, IA - OSPF inter area, N1 - OSPF NSSA external type 1,
N2 - OSPF NSSA external type 2, E1 - OSPF external type 1,
E2 - OSPF external type 2, * - candidate default,
+ - summary route, > - non-active route
Gateway of last resort is not set
Destination Gateway Dist/Metric Last Change
-------------------------------------------------------------------------------
B EX 10.0.1.2/32 via 192.168.1.1 20/0 00:54:54
via 192.168.1.3
via 192.168.1.5
via 192.168.1.7
B EX 10.0.2.1/32 via 192.168.1.1 20/0 00:55:44
B EX 10.0.2.2/32 via 192.168.1.3 20/0 00:54:54
B EX 10.0.2.3/32 via 192.168.1.5 20/0 01:38:06
B EX 10.0.2.4/32 via 192.168.1.7 20/0 01:37:52
B EX 172.16.1.0/24 via 192.168.1.1 20/0 00:54:54
via 192.168.1.3
B EX 172.16.2.0/24 via 192.168.1.5 20/0 01:37:49
via 192.168.1.7
S4048-Leaf1# show ip route bgp
Codes: C - connected
S - static
B - BGP, IN - internal BGP, EX - external BGP
O - OSPF, IA - OSPF inter area, N1 - OSPF NSSA external type 1,
N2 - OSPF NSSA external type 2, E1 - OSPF external type 1,
E2 - OSPF external type 2, * - candidate default,
+ - summary route, > - non-active route
Gateway of last resort is not set
Destination Gateway Dist/Metric Last Change
-------------------------------------------------------------------------------
B EX 10.0.1.1/32 via 192.168.1.0 20/0 01:00:13
B EX 10.0.1.2/32 via 192.168.2.0 20/0 01:00:11
B EX 10.0.2.2/32 via 192.168.1.0 20/0 00:59:23
via 192.168.2.0
B EX 10.0.2.3/32 via 192.168.1.0 20/0 01:00:11
via 192.168.2.0
B EX 10.0.2.4/32 via 192.168.1.0 20/0 01:00:11
via 192.168.2.0

Dell S3048-ON Specifications

General

Rack Units	1U
Form Factor	Rack-mountable
Input Voltage	100-240V AC
Power Supply	2 hot-swappable power supplies
Management	CLI, Web, SNMP
Product Type	Switch
MAC Address Table Size	32K entries
Jumbo Frame Support	Yes
Latency	< 3 microseconds
Ports	48 x 1GbE RJ45, 4 x 10GbE SFP+
