64 Dell EMC Networking with Isilon Front-End Deployment and Best Practices Guide | version 1.0
S4048-Leaf3#show ip route bgp
Destination Gateway Dist/Metric Last Change
----------- ------- ----------- -----------
B EX 10.0.1.1/32 via 192.168.1.4 20/0 00:21:22
B EX 10.0.1.2/32 via 192.168.2.4 20/0 00:21:22
B EX 10.0.2.1/32 via 192.168.1.4 20/0 00:21:22
via 192.168.2.4
B EX 10.0.2.2/32 via 192.168.1.4 20/0 00:21:22
via 192.168.2.4
B EX 10.0.2.4/32 via 192.168.1.4 20/0 00:20:27
via 192.168.2.4
B EX 172.16.1.0/24 via 192.168.1.4 20/0 00:21:22
via 192.168.2.4
Note: The command show ip route <cr> can also be used to verify the information above as well as
static routes and direct connections.
8.2.3 Show VLT brief
This command is used to validate VLT configuration status on leaf switches in this topology. The Inter-chassis
link (ICL) Link Status, Heart Beat Status and VLT Peer Status must all be up. The role of one switch in the
VLT pair is primary (not shown), and its peer switch is assigned the secondary role. Ensure peer routing is
shown as enabled.
S4048-Leaf3#show vlt brief
VLT Domain Brief
------------------
Domain ID: 127
Role: Secondary
Role Priority: 32768
ICL Link Status: Up
HeartBeat Status: Up
VLT Peer Status: Up
Local Unit Id: 0
Version: 6(8)
Local System MAC address: f4:8e:38:2e:a0:f7
Remote System MAC address: f4:8e:38:2e:76:f7
Remote system version: 6(8)
Delay-Restore timer: 90 seconds
Delay-Restore Abort Threshold: 60 seconds
Peer-Routing : Enabled
Peer-Routing-Timeout timer: 0 seconds
Multicast peer-routing timeout: 150 seconds
