Parameter
Value
Interface int-a netmask
255.255.255.0
Interface int-a IP Range
10.10.10.1-253
Interface int-b netmask
255.255.255.0
Interface int-b IP Range
10.10.20.1-253
Failover IP range
10.10.30.1-253
Interface ext-1 netmask
255.255.255.0
MTU
1500
Interface ext-1 IP pool
100.67.170.140-148
ext-1 default gateway
100.67.170.254
SmartConnect Zone name
Mgmtzone1
SmartConnect service IP
100.67.170.149
DNS servers
100.67.10.1
Search domain
dell.local
Cluster date and time
Default
Cluster join mode
Default
Commit changes
Yes
Note: Additional information and configuration for SmartConnect will be provided in Section 9.5.
When the first node is configured, and the cluster has been created, the other nodes can then be added into
the cluster. All nodes will be able to discover the cluster over the back-end network. The assorted options for
back-end networking and Isilon are not covered in this document, for more information on the back-end
network refer to Isilon documentation.
1. At the login screen of node two, select [ 2] Join existing cluster.
2. The cluster that was created will be displayed, select 1 to add node two to Cluster-01.
3. Repeat for all nodes that need to be added to the cluster. Each node will be dynamically assigned an IP
address out of the IP pool that was designated in the cluster creation.

Dell S3048-ON Specifications

General

Rack Units	1U
Form Factor	Rack-mountable
Input Voltage	100-240V AC
Power Supply	2 hot-swappable power supplies
Management	CLI, Web, SNMP
Product Type	Switch
MAC Address Table Size	32K entries
Jumbo Frame Support	Yes
Latency	< 3 microseconds
Ports	48 x 1GbE RJ45, 4 x 10GbE SFP+
