12 │ About your monitor
Side view
Bottom view
7 952 1043 8
6
1
Bottom view without monitor stand
Label Description Use
1 Security-lock slot Secure your monitor using a security lock (purchased
separately) to prevent unauthorized movement of your
monitor.
2 Power connector Connect the power cable (shipped with your monitor).
3 HDMI 1 2.0 port Connect to your computer using a HDMI cable.
4 HDMI 2 2.0 port Connect to your computer using a HDMI cable.
5 Stand lock
feature
Lock the stand to the monitor using a M3 x 6 mm
screw (screw not included).
6 DP 1.2 port Connect to your computer using a DP cable.
7 Audio line out
port
Connect to an external speaker or a sub-woofer
(purchased separately).*
8 USB 3.0
upstream port
Connect the USB cable from this port to your
computer to enable the USB ports on your monitor.
