26 │ Setting up the monitor
5
6.
Place the monitor upright.
Connecting your monitor
WARNING: Before you begin any of the procedures in this section,
follow the Safety Instructions.
NOTE: Do not connect all cables to the computer at the same time. It
is recommend to route the cables through the cable-management slot
before you connect them to the monitor.
To connect your monitor to the computer:
1.
Turn off your computer and disconnect the power cable.
2.
Connect the HDMI or DP cable (optional purchase) from your monitor to the
computer.
3.
Connect the USB upstream cable (shipped with your monitor) to an
appropriate USB 3.0 port on your computer. (See Bottom view for details.)
4.
Connect the USB 3.0 peripherals to the downstream USB 3.0 ports on the
monitor.
Connecting the HDMI and USB 3.0 cable
USB
USB
HDMI 2.0 HDMI 2.0
HDMI 2.0
HDMI 2.0
HDMI 2.0
5.
Connect the power cables from your computer and monitor into a wall outlet.
