NOTE: Retain the castings for future rack requirements.
1. Remove the flange ear castings from each end of the ReadyRails assemblies. Remove the two screws
from each flange ear, and remove each casting with a Torx driver, as shown in item 1 in the figure.
2. For each rail, attach the front and rear flanges to the post flanges with two user-supplied screws at
each end, as shown in items 2 and 3 in the following figure.
Figure 7. Four-post Threaded Configuration
24
Install the Hardware
