50 | Setting up the monitor
Make sure to set Thunderbolt
TM
4 to On in Off Mode. While the PC and two monitors
are in an initially OFF power state, by pressing the power button on Monitor 1 or
Monitor 2 will turn ON the PC, Monitor 1, and Monitor 2.
Monitor 1
Monitor 2
System power state(OFF)
90W
Thunderbolt
TM
4
upstream
90W
Thunderbolt
TM
4
upstream
port1
Thunderbolt
TM
4
port2
Thunderbolt
TM
4
Pressing power button on Monitor 1 or 2
Monitor 1
Monitor 2
System power state(ON)
90W
Thunderbolt
TM
4
upstream
90W
Thunderbolt
TM
4
upstream
port1
Thunderbolt
TM
4
port2
Thunderbolt
TM
4
