Setting up the monitor | 53
VESA wall mounting (optional)
NOTE: Use M4 x 11 mm screws to connect the monitor to the wall-
mounting kit.
Refer to the instructions that come with the VESA-compatible wall mounting kit.
1. Place the monitor on a soft cloth or cushion on a stable flat table.
2. Remove the stand (See Removing the monitor stand).
3. Use a Phillips crosshead screwdriver to remove the four screws securing the
plastic cover.
4. Attach the mounting bracket from the wall-mounting kit to the monitor.
5. Mount the monitor on the wall. For more information, see the documentation that
shipped with the wall-mounting kit.
NOTE: For use only with UL or CSA or GS-listed wall mount bracket with
minimum weight or load bearing capacity of 20.92 kg (46.12 lb) .
